HK Audio Linear 9 118 Sub BA – Dual 18″ Vented Bandpass Active Subwoofer
R83,795.00
HK AUDIO LINEAR 9 118 Sub BA Powered 1100W 18″ Dual Vented Bandpass Subwoofer
Audio professionals looking for a powered networked subwoofer with expansion options will be impressed with the HK Audio LINEAR 9 118 Sub BA, a dual-vented bandpass subwoofer with an integrated 1100W RMS (2200 program) amplifier that powers the 18″ woofer and produces frequencies as low as 38 Hz with a maximum SPL of 136 dB.
The LINEAR 9 Series is the latest flagship model in the HK Audio LINEAR family and was developed with the needs and demands of rental companies and event companies in mind, all of whom require a reliable, versatile, future-proof, economical, and, at the same time, an acoustically and mechanically superior sound tool suitable for many years of daily use.
Features
- 1100W RMS / 2200 Program
- Low-Frequency Extension to 38 Hz
- 136 dB Maximum SPL
- Network Controllable DSP with 4 Presets
- Front, Cardioid 1:1, Cardioid 2:1, Remote
- DSP: 10-Band Parametric EQ, Mute
- HPF, LPF, Polarity, Level, Delay, Limit
- Powerful Punch, Precise Playback
- Lightweight and Easy to Transport
- Limited 5-Year Warranty
Specifications
Enclosure Type |
Bandpass Subwoofer
|
Total Power Capacity |
1100 W RMS
2200 W Program 4400 W Peak |
Amplifier Class |
Class-D
|
Drivers
HF Driver |
None
|
MF Driver |
None
|
LF Driver |
1 x 18″ / 457.2 mm Woofer
|
LF Voice Coil |
4″ / 101.6 mm
|
Performance
Frequency Range |
31 Hz -10 dB
|
Frequency Response |
38 Hz ±3 dB
|
Maximum SPL |
136 dB (Half-Space)
|
Max Input Level |
+20 dB
|
Gain Range |
-6 dB to +6 dB
|
Protections |
Signal Limiter
|
Connectivity
Audio I/O |
2 x Combo XLR-1/4″ 3-Pin Female Balanced/Unbalanced Line Input
2 x XLR 3-Pin Male Balanced Line Thru 1 x XLR 3-Pin Male Balanced Output |
Network I/O |
2 x RJ45 (Control) In/Out
|
USB |
None
|
Wireless Connectivity |
None
|
Mobile App Compatible |
No
*As of January 2023: Check with the manufacturer for the most up-to-date compatibility |
Signal Processing
EQ |
Yes
|
Parametric EQ |
Yes
|
Semi-Parametric EQ |
None
|
Filters |
1 x High-Pass
1 x Low-Pass |
Dynamic Processing |
Limiter, Peak Limiter
|
Alignment Delay |
Yes
|
Phase Adjustment |
Yes
|
Digital Signal Processing |
24-Bit DSP: Delay, User Settings (Adjustable via Optional Software)
|
Maximum Sampling Rate |
96 kHz / 24-Bit
|
Power
AC Input Power |
100 to 240 VAC, 50 / 60 Hz
|
AC Power I/O |
1 x powerCON Input
1 x powerCON Output |
Current Consumption |
1.9 A (Typical)
|
Physical
Mounting |
2 x M20 Pole Socket
|
Handles |
2 x Each Side
2 x Top 2 x Bottom |
Construction Material |
Metal Grille, Wood
|
Dimensions |
43.7 x 22 x 27.2″ / 111 x 56 x 69 cm
|
Weight |
140 lb / 63.5 kg
|
