HK Audio Linear 9 118 Sub A – 18″ Active Subwoofer
R58,795.00
HK AUDIO LINEAR 9 112 XA Powered 700W 12″ 2-Way Loudspeaker
Audio professionals looking for a professional powered loudspeaker will be impressed with the HK Audio LINEAR 9 112 XA, a mid/high speaker equipped with a rotating 70 x 50° horn that allows the speaker to be deployed horizontally or vertically. The 700W (2800W peak) Class-D amplifier powers the 1″ high-frequency (HF) driver and 12″ woofer, which combine for a full-range sound (67 Hz to 19 kHz) with a maximum SPL of 131 dB.
The rear panel features a pair of RJ45 network ports that connect to the internal speaker DSP as well as four factory presets. For I/O, the 112 XA features a combo XLR-1/4″ input and XLR output. A DSP XLR output provides a networked DSP-controlled channel for non-network speakers. A power cord is included.
Features
- 700W RMS / 1400W Program
- 67 Hz to 19 kHz Frequency Response
- 131 dB Maximum SPL (Peak)
- 70 x 50° Rotatable Horn
- Network Controllable DSP with 4 Presets
- Flat, Monitor, Low Cut, Remote
- DSP: 10-Band Parametric EQ, Mute
- HPF, LPF, Polarity, Level, Delay, Limit
- Lightweight and Easy to Transport
- Limited 5-Year Warranty
Specifications
Enclosure Type |
Bass-Reflex Loudspeaker
|
Total Power Capacity |
700 W RMS
|
Amplifier Class |
Class-D
|
Drivers
HF Driver |
1 x 1″ / 2.5 cm Rotatable Horn
|
HF Voice Coil |
1.7″ / 4.3 cm
|
MF Driver |
None
|
LF Driver |
1 x 12″ / 304.8 mm Woofer
|
LF Voice Coil |
2.5″ / 63.5 mm
|
Performance
Frequency Range |
62 Hz to 20 kHz -10 dB
|
Frequency Response |
67 Hz to 19 kHz ±3 dB
|
Maximum SPL |
131 dB (Half-Space)
|
Coverage Angle |
70° H x 50° V (Rotatable Horn)
|
Max Input Level |
+20 dB
|
Gain Range |
-12 dB to +6 dB
|
Protections |
Signal Limiter
|
Connectivity
Audio I/O |
1 x Combo XLR-1/4″ 3-Pin Female Balanced/Unbalanced Line Input
1 x XLR 3-Pin Male Balanced Line Thru 1 x XLR 3-Pin Male Balanced Output |
Network I/O |
2 x RJ45 (Control) In/Out
|
USB |
None
|
Wireless Connectivity |
None
|
Mobile App Compatible |
No
*As of March 2023: Check with the manufacturer for the most up-to-date compatibility |
Signal Processing
Crossover |
1.6 kHz
|
EQ |
Yes
|
Parametric EQ |
Yes
|
Semi-Parametric EQ |
None
|
Filters |
1 x High-Pass
1 x Low-Pass |
Dynamic Processing |
Limiter, Peak Limiter
|
Alignment Delay |
Yes
|
Phase Adjustment |
Yes
|
Digital Signal Processing |
24-Bit DSP: Delay, User Settings (Adjustable via Optional Software)
|
Maximum Sampling Rate |
96 kHz / 24-Bit
|
Power
AC Input Power |
100 to 240 VAC, 50 / 60 Hz
|
AC Power I/O |
1 x powerCON Input
1 x powerCON Output |
Current Consumption |
1 A (Typical)
|
Physical
Mounting |
5 x M8 Fly Point
Pole Socket (Dual Angle, Bottom) |
Handles |
1 x Top
1 x Side |
Construction Material |
Metal Grille, Wood
|
Dimensions |
26.4 x 14.6 x 12.2″ / 67 x 37 x 31 cm
|
Weight |
99.6 lb / 45.2 kg
|
