NuX B-7PSM – Wireless In-Ear Monitoring System
R3,395.00
3 in stock
NUX B-7PSM – 5.8 GHz Wireless In-Ear Monitoring System
CUT THE CORD. BE IN COMMAND!
The NUX B-7PSM is a wireless personal in-ear monitor system with automatic RF environment scan, 5.8GHz interference-free broadcasting frequency, and 24-bit / 40 kHz high-quality STEREO audio transmitting.
From any position. On any stage. Hear every note in detail with NUX B-7PSM in-ear monitoring system.
It quickly finds a clean wireless channel and automatically assigns it. The B-7PSM offers a super low latency of less than 5.5ms and has an operation range of 100 feet (30m) when unobstructed between the Receiver (RX) and Transmitter (TX). (The operation range is around 32 feet (10m) when obstructed). It’s a super light-weight wireless, mini-compact system designed to clip on & go. The TX features a 1/8” TRS plug (you can use the included adaptor to convert to 1/4”), broadcaster-grade audio via 5.8GHz digital transmission to the compact RX. The RX’s clip design can easily fit to your shirt, belt, or guitar strap. And, with our newest automatic frequency hopping technology, B-7PSM is reliable and stable while you perform on stage.
Note 1: When coupling multiple B-7PSM systems, please turn on 1 set first, pair it, and then turn on the other sets sequentially.
Note 2: For best results the TX should be at least 1 meter above the ground, 2 meters away from Wi-Fi routers and wall or metal surfaces to minimize reflections.
EASY TO USE
The user-friendly matching system makes it easy to use, just turn ON both wireless units (TX & RX), then it will be paired within a couple of seconds. Each wireless set has a unique pairing algorithm, it automatically detects each other and configures their own IDs. The signal never interferes with any other wireless including the WiFi* signal.
*Recommended: Please stay 2 meters (6 feet) away from the Wifi router for the best results.
Specifications
- Output Volume Adjustment – -64dB~0dB (0.5dB step)
- Operating Frequency Band – 5.8 GHz
- Operation Length – < 100 feet (30m) outdoor unobstructed, < 33 feet (10m) outdoor with obstructions
- Sampling Rate – 24bit / 40 kHz
- Frequency Response – 20~19kHz
- Latency – < 5.5ms
- Dynamic Range – 92 dB
- THD+ Noise – <0.6%@1kHz
- Built-in Battery Capacity (TX & RX) – 450mAh / 3.7V
- Battery Running Time – > 4 hours
- Battery Charging Time – around 1.5 hours
- Power Consumption – TX <90mA,RX < 45mA
- TX Impedance – 3.5kΩ
- Maximum Input Level – 7.6Vpp (8.6dBV or 2.7Vrms)
- RX Suggestion Phone Impedance – 16~32Ω
- Maximum Output Power – 57mWrms (RLOAD =16Ω, 1 kHz).
