HK AUDIO LINEAR 9 110 XA Powered 700W 10″ 2-Way Loudspeaker
Audio professionals looking for a professional powered loudspeaker will be impressed with the HK Audio LINEAR 9 110 XA, a mid/high speaker equipped with a rotating 80° and 60° horn that allows the speaker to be deployed horizontally or vertically. The 700W RMS Class-D amplifier powers the 1″ high-frequency (HF) driver and 10″ woofer, which combine for a full-range sound (70 Hz to 19 kHz) with a maximum SPL of 129 dB.
The rear panel features a pair of RJ45 network ports that connect to the internal speaker DSP as well as four factory presets. For I/O, the 110 XA features a combo XLR-1/4″ input and XLR output. A DSP XLR output provides a networked DSP-controlled channel for non-network speakers. A power cord is included.
Features
- 700W RMS / 1400W Program
- 70 Hz to 19 kHz Frequency Response
- 129 dB Maximum SPL
- 80° and 60° Rotatable Horn
- Network Controllable DSP with 4 Presets
- Flat, Monitor, Low Cut, Remote
- DSP: 10-Band Parametric EQ, Mute
- HPF, LPF, Polarity, Level, Delay, Limit
- Lightweight and Easy to Transport
- Limited 5-Year Warranty
Specification
Configuration |
Active 2-Way
|
Enclosure Type |
Bass-Reflex Loudspeaker
|
Total Power Capacity |
700 W RMS
|
HF Driver |
1 x 1″ / 2.5 cm Rotatable Horn
|
LF Driver |
1 x 10″ / 254 mm Woofer
|
Frequency Range |
65 Hz to 20 kHz -10 dB
|
Enclosure Type |
Bass-Reflex Loudspeaker
|
Total Power Capacity |
700 W RMS
|
Amplifier Class |
Class-D
|
Drivers
HF Driver |
1 x 1″ / 2.5 cm Rotatable Horn
|
HF Voice Coil |
1.4″ / 3.6 cm
|
MF Driver |
None
|
LF Driver |
1 x 10″ / 254 mm Woofer
|
LF Voice Coil |
2.5″ / 63.5 mm
|
Performance
Frequency Range |
65 Hz to 20 kHz -10 dB
|
Frequency Response |
70 Hz to 19 kHz 3 dB
|
Maximum SPL |
129 dB (Half-Space)
|
Coverage Angle |
80° H x 60° V (Rotatable Horn)
|
Max Input Level |
+20 dB
|
Gain Range |
-12 dB to +6 dB
|
Protections |
Signal Limiter
|
Connectivity
Audio I/O |
1 x Combo XLR-1/4″ 3-Pin Female Balanced/Unbalanced Line Input
1 x XLR 3-Pin Male Balanced Line Thru 1 x XLR 3-Pin Male Balanced Output |
Network I/O |
2 x RJ45 (Control) In/Out
|
USB |
None
|
Wireless Connectivity |
None
|
Mobile App Compatible |
No
*As of March 2023: Check with the manufacturer for the most up-to-date compatibility |
Signal Processing
Crossover |
2 kHz
|
EQ |
Yes
|
Parametric EQ |
Yes
|
Semi-Parametric EQ |
None
|
Filters |
1 x High-Pass
1 x Low-Pass |
Dynamic Processing |
Limiter, Peak Limiter
|
Alignment Delay |
Yes
|
Phase Adjustment |
Yes
|
Digital Signal Processing |
24-Bit DSP: Delay, User Settings (Adjustable via Optional Software)
|
Maximum Sampling Rate |
96 kHz / 24-Bit
|
Power
AC Input Power |
100 to 240 VAC, 50 / 60 Hz
|
AC Power I/O |
1 x powerCON Input
1 x powerCON Output |
Current Consumption |
1 A (Typical)
|
Physical
Mounting |
Pole Socket (Dual Angle, Bottom)
|
Handles |
1 x Top
1 x Side |
Construction Material |
Metal Grille, Wood
|
Dimensions |
21.3 x 14.2 x 12.2″ / 54 x 36 x 31 cm
|
Weight |
36.4 lb / 16.5 kg
|
