Austrian Audio OC18 Studio Set – Large-Diaphragm Cardioid Condenser Mic w/ Spider Mount, Mic Clip, Windshield & Case [OC18STUDIO]
R16,200.00
Austrian Audio OC18 Studio Set Large-Diaphragm Cardioid Condenser Microphone
Designed by a team of former AKG personnel, the Austrian Audio OC18 Studio Set is a large-diaphragm studio condenser microphone offering detailed audio capture for vocalists, voiceover artists, musicians, and producers in personal and commercial recording facilities. The handmade 1″ ceramic capsule features a gold-plated polymer membrane and a cardioid polar pattern, which yields reliable on-axis directivity with enhanced off-axis rejection. Front-panel switches are provided for easy access to the pad and roll-off settings.
Set the pad to -10 or -20 dB to avoid distortion when miking loud sources such as drums or guitar cabinets. Activate the high-pass filter at 40, 80, or 160 Hz for attenuation of low-frequency problems including rumble and proximity effect. The OC18’s housing is constructed of zinc-aluminum alloy for strength and durability. The OC18 Studio Set includes a vibration-reducing shockmount, a traditional mic clip, a windscreen for mitigating noise from breaths and blasts of air, and a protective carry case. Being 48 VDC phantom powered, the OC18 does not require batteries or an external power supply.
Features
- For Vocals/Instruments in Studio & Stage
- Cardioid Pattern Lowers Background Noise
- Selectable Pad at -10 or -20 dB
- Selectable 40/80/160 Hz High-Pass Filter
- Handmade 1″ Ceramic Capsule
- Gold-Plated Polymer Membrane
- Durable Zinc-Aluminum Alloy Construction
- Includes Shockmount and Mic Clip
- Includes Windscreen and Carry Case
- 48 VDC Phantom Powered
Specifications
Microphone
Primary Applications |
Studio Recording
|
Form Factor |
Large Diaphragm Mic / Stand/Boom Mount
|
Intended Sound Sources |
Vocals, Speech/Voice-Over, Instruments
|
Sound Field |
Mono
|
Element Type |
Condenser
|
Diaphragm |
1″ / 25.40 mm
|
Polar Pattern |
Cardioid
|
Orientation |
Side Address
|
Circuitry |
Solid-State
|
Pad |
-10 dB
-20 dB |
High-Pass Filter |
40 Hz, 12 dB/Octave
80 Hz, 12 dB/Octave 160 Hz, 6 dB/Octave |
On-Board Controls |
High-Pass Filter, Pad
|
Performance
Frequency Range |
20 Hz to 20 kHz
|
Maximum SPL |
148 dB SPL
|
Impedance |
275 Ohms
|
Load Impedance |
> 1000 Ohms
|
Sensitivity |
13 mV/Pa
|
Equivalent Noise Level |
9 dB SPL A-Weighted
|
Connectivity
Analog Output |
1x XLR 3-Pin Male (on Mic)
|
Power
Power Sources |
Phantom Power
|
Operating Voltage |
V ()
|
Physical
Color |
Black
|
Construction Material |
Zinc Alloy
|
Dimensions |
H: 1.4 x W: 2.5 x L: 6.2″ / H: 3.5 x W: 6.3 x L: 15.7 cm
|
Weight |
12.52 oz / 355 g
|
